Steel sheet pile is a structural steel product designed with interlocking edges, allowing each pile to connect tightly with the next one. After driving into the ground, sheet piles form a continuous steel wall that provides strong resistance against soil pressure, water pressure, and construction load.
Because of its high strength, fast installation, reusable performance, and excellent structural stability, steel sheet pile is widely used in temporary and permanent engineering projects, including deep excavation, cofferdams, retaining walls, bridge foundations, port terminals, flood control, and riverbank protection.
Henan GDD supplies hot rolled and cold formed steel sheet piles in U type, Z type, and customized sections. We support different steel grades, lengths, surface treatments, and shipment solutions according to project requirements.
| Item | Specification |
|---|---|
| Product Name | Steel Sheet Pile |
| Type | U Type, Z Type, Straight Web Type, Customized Profile |
| Process | Hot Rolled / Cold Formed |
| Steel Grade | Q235B, Q345B, Q355B, S355JR, S355JO, SY295, SY390, ASTM A572 Gr.50 |
| Standard | GB, ASTM, EN, JIS or Customized Standard |
| Length | 6m, 9m, 12m, 15m, 18m or Customized |
| Thickness | Customized according to profile and project requirement |
| Surface Treatment | Black Steel, Painted, Galvanized, Anti-corrosion Coating |
| Edge Design | Interlocking Clutch / Locking System |
| Inspection | MTC, Dimension Inspection, Visual Inspection, Third-party Inspection |
| Application | Retaining Wall, Cofferdam, Port, Bridge, Foundation, River Protection |
| Trade Terms | FOB, CFR, CIF, EXW |
| Loading Port | China Main Ports |
| MOQ | According to size and stock availability |
U type steel sheet pile is one of the most commonly used profiles in construction projects. It has good section modulus, stable locking performance, and strong bending resistance. It is widely used for retaining walls, riverbank protection, temporary excavation support, and cofferdam projects.
Z type steel sheet pile has a more optimized section structure and higher strength-to-weight ratio. It is suitable for large-scale foundation engineering, ports, deep excavation, marine projects, and permanent retaining structures.
For special project requirements, customized profiles, lengths, steel grades, and surface coatings can be supplied according to engineering drawings or technical specifications.
Steel sheet piles are used in many infrastructure and construction projects where soil retention, water control, or foundation support is required.
Common applications include:
| Application Area | Usage |
|---|---|
| Retaining Wall | Soil retention for excavation and slope protection |
| Cofferdam | Temporary water-blocking structure for bridge and marine works |
| Port Construction | Wharf, dock, quay wall, and marine foundation |
| Bridge Foundation | Foundation support and water isolation |
| Riverbank Protection | Flood control, embankment reinforcement, and erosion prevention |
| Basement Excavation | Deep foundation pit support |
| Road and Railway Projects | Slope support and structural reinforcement |
| Temporary Works | Reusable steel wall for short-term construction projects |
Steel sheet piles are manufactured from high-strength structural steel, offering excellent resistance to bending, impact, soil pressure, and water pressure.
The interlocking edges allow each sheet pile to connect tightly, forming a continuous wall with good sealing and load-bearing performance.
Steel sheet piles can be installed by vibratory hammer, hydraulic press, or impact hammer, reducing construction time and improving project efficiency.
For temporary construction projects, steel sheet piles can be extracted and reused, helping reduce total project cost.
With proper coating, painting, or galvanizing, steel sheet piles can be used in marine, port, river, and high-humidity environments.
Different lengths, grades, surface treatments, and profiles can be supplied according to project drawings and engineering requirements.
Henan GDD is a professional steel material supplier with rich experience in steel processing, warehousing, and export service. We provide stable steel sheet pile supply for construction companies, steel distributors, contractors, infrastructure projects, and engineering procurement companies.
Our advantages include:
| Advantage | Description |
|---|---|
| Stable Supply | Support stock and customized production |
| Multiple Grades | Chinese, Japanese, European, and ASTM grades available |
| Project Support | Can supply according to drawings and technical specifications |
| Quality Control | Dimension inspection, surface inspection, and MTC support |
| Export Experience | Support global shipping and export documentation |
| Flexible Trade Terms | FOB, CIF, CFR, EXW available |
| One-stop Service | Quotation, production, inspection, loading, and shipment support |
Before shipment, we can provide strict quality inspection according to customer requirements.
Inspection items may include:
| Inspection Item | Details |
|---|---|
| Dimension Check | Length, width, thickness, profile tolerance |
| Surface Inspection | Rust, cracks, deformation, edge quality |
| Interlock Inspection | Clutch connection and locking performance |
| Quantity Check | Bundle quantity and total weight |
| Material Certificate | MTC / Mill Test Certificate available |
| Third-party Inspection | SGS, BV, Intertek, or customer-appointed inspection accepted |
Steel sheet piles are usually packed in bundles with steel strips. For export shipment, loading can be arranged by bulk vessel, container, or break bulk shipment depending on length, quantity, and destination port.
| Item | Details |
|---|---|
| Packing | Steel strip bundle, export standard packing |
| Marking | Grade, size, heat number, bundle number if required |
| Loading Method | Container, bulk vessel, break bulk |
| Shipping Terms | FOB, CFR, CIF, EXW |
| Documents | Commercial Invoice, Packing List, BL, MTC, COO if required |
Yes. We can supply U type, Z type, and customized steel sheet pile profiles according to project requirements.
Common grades include Q235B, Q355B, S355JR, SY295, SY390, and ASTM A572 Gr.50. Other grades can be confirmed according to your specification.
Yes. Please send us your drawings, required length, steel grade, quantity, destination port, and application. We will check production feasibility and provide a quotation.
Yes. MTC can be provided with the shipment. Third-party inspection is also available if required.
We can supply black steel, painted surface, galvanized surface, or anti-corrosion coating according to project needs.
Please provide profile type, steel grade, length, quantity, surface treatment, destination port, and trade terms such as FOB, CIF, or CFR.
Yes. For temporary projects, steel sheet piles can often be extracted and reused after construction, depending on site conditions and pile condition.
