Steel Sheet Pile – Interlocking steel pile for retaining walls and foundations.
U Type & Z Type Available – Suitable for cofferdams, ports, bridges and excavation support.
Custom Project Supply – Length, section type, thickness and steel grade can be customized.
Strong Structural Support – Good bending strength, interlock performance and installation efficiency.
Export Ready Service – MTC, inspection support, bundle packing, FOB, CIF and CFR available.
Steel sheet pile is a long structural steel section with interlocking edges. When installed side by side, the interlocks connect each sheet pile into a continuous wall system. This wall can resist soil pressure, water pressure and construction loads in excavation, foundation and waterfront projects.
Because of its high structural strength, fast installation and reusable performance, steel sheet pile is widely used in retaining walls, cofferdams, bridge foundations, port construction, riverbank protection, basement excavation, road construction and flood control projects.
Henan GDD supplies steel sheet piles in various section types, steel grades, lengths and surface treatments. We support contractors, project buyers, foundation engineering companies, port construction suppliers and global steel distributors.
| Item | Specification |
|---|---|
| Product Name | Steel Sheet Pile / Steel Piling / Sheet Pile |
| Section Type | U Type, Z Type, Straight Web Type, Customized Section |
| Production Type | Hot Rolled / Cold Formed |
| Material Grade | SY295, SY390, Q235B, Q355B, S275, S355, ASTM A572 Gr.50 or Customized |
| Standard | JIS, EN, ASTM, GB or Customized |
| Thickness | 6 mm – 18 mm or Customized |
| Width | 400 mm – 750 mm or Customized |
| Length | 6m, 9m, 12m, 18m, 24m or Customized |
| Surface Treatment | Black, Painted, Galvanized, Epoxy Coated or Customized |
| Interlock Type | Standard Interlock / Customized Interlock |
| Processing Service | Cutting, Welding, Drilling, Coating, Length Customization |
| Application | Retaining Wall, Cofferdam, Port, Bridge, Riverbank, Foundation, Basement Excavation |
| Inspection | MTC, Dimension Inspection, Surface Inspection, Interlock Inspection, Third-party Inspection |
| Packing | Bundle Packing with Steel Strips |
| Trade Terms | FOB, CFR, CIF, EXW |
Steel sheet pile is a special steel profile used in civil engineering and foundation projects. Its interlocking design allows multiple piles to form a continuous steel wall, which can support soil, block water and protect excavation areas.
The sheet pile wall can be used as a temporary structure during construction or as a permanent structure in ports, riverbanks, retaining walls and flood protection systems.
Steel sheet piles are usually installed by vibratory hammer, hydraulic press-in machine or impact hammer, depending on soil condition, project design and construction method.
U type steel sheet pile is one of the most commonly used sheet pile sections. It has good bending resistance, stable interlock performance and wide application range. It is suitable for retaining walls, cofferdams, riverbank protection, excavation support and foundation projects.
Z type steel sheet pile has excellent section modulus and high strength-to-weight efficiency. It is suitable for heavy-duty retaining walls, deep excavation, port projects and structures requiring higher bending capacity.
Hot rolled steel sheet pile is produced through hot rolling and has strong interlock performance, stable shape and reliable structural strength. It is widely used in permanent and heavy-duty construction projects.
Cold formed steel sheet pile is produced by forming steel coil or plate at room temperature. It offers flexible section design and can be used for light to medium-duty retaining structures, temporary works and customized project needs.
Customized sheet piles can be supplied according to project drawings, including special length, section size, steel grade, coating, welding, cutting and interlock requirements.
Steel sheet piles are widely used in retaining wall systems for roads, railways, basements, underground structures and slope protection. They help stabilize soil and prevent collapse during excavation or long-term use.
In waterfront engineering, sheet piles are used for ports, wharfs, docks, seawalls, riverbanks, canals and flood protection structures. They can resist water pressure and protect shorelines from erosion.
For bridge and foundation projects, steel sheet piles are often used to build cofferdams, temporary enclosures and foundation protection systems. They help create a safe and dry working area for construction.
Steel sheet piles are also used in drainage projects, tunnel entrances, industrial foundations, temporary construction works and environmental protection barriers.
Steel sheet piles provide high bending strength and stable wall support, making them suitable for soil retention, water control and foundation protection.
The interlocking system allows quick installation and continuous wall formation, helping reduce project time and improve construction efficiency.
For temporary cofferdams or excavation support, steel sheet piles can often be extracted and reused, reducing overall project cost.
Steel sheet piles can be used in soft soil, waterfront areas, deep excavation sites and limited-space construction environments.
Different section types, steel grades, lengths and coatings can be selected according to soil condition, water pressure, load requirement and project design.
Steel sheet piles can be supplied in bundles with export packing, inspection documents and shipment support for international construction projects.
U type sheet pile is widely used and suitable for general retaining walls, cofferdams and foundation support projects. It is easy to handle and has stable interlock performance.
Z type sheet pile usually provides higher section efficiency and bending capacity. It is often selected for deeper excavation, port construction, heavy retaining walls and projects with higher structural requirements.
The correct choice depends on soil pressure, water level, excavation depth, design load, installation method and project budget.
Steel sheet piles can be supplied with black surface for general use. Painted surface, epoxy coating, galvanized surface or other anti-corrosion treatment can be arranged for projects requiring better corrosion resistance.
For marine, riverbank and long-term exposed environments, coating selection is important. Customers can choose surface protection according to project service life, water condition and corrosion level.
Henan GDD is a reliable steel material supplier with experience in structural steel supply, steel processing, inspection, packing and export service. We provide steel sheet pile solutions for foundation engineering companies, port construction projects, bridge contractors, road projects, excavation support suppliers and global steel distributors.
We support U type and Z type sheet piles, multiple steel grades, custom lengths, coating options, cutting service, inspection documents and international shipment. From quotation to production, inspection, packing and loading, our team can provide one-stop export support for your steel sheet pile orders.
Before shipment, Henan GDD can arrange inspection according to customer requirements. Inspection items may include section size, thickness, width, length, straightness, interlock condition, surface quality, bundle quantity and total weight.
For project orders, chemical composition, mechanical properties, coating condition and third-party inspection can also be arranged according to customer requirements. MTC, quality documents, inspection photos, packing photos, loading photos and third-party inspection reports can be provided with shipment.
Steel sheet piles are usually packed in bundles with steel strips. Bundle weight, bundle size, tags, marks and loading plan can be arranged according to customer requirements.
Standard and customized lengths can be supplied according to project needs. Shipment can be arranged by container, bulk vessel or break bulk shipment depending on sheet pile length, order quantity and destination port.
Export documents such as commercial invoice, packing list, bill of lading, MTC and certificate of origin can be provided according to buyer requirements.
Steel sheet pile is used for retaining walls, cofferdams, ports, bridges, riverbank protection, basement excavation, foundation support, flood control and infrastructure projects.
U type sheet pile is widely used for general retaining and cofferdam projects. Z type sheet pile usually has higher section efficiency and is suitable for heavier retaining structures and deeper excavation.
Yes. Length can be customized according to project requirements, transportation method and installation design.
Common grades include SY295, SY390, Q235B, Q355B, S275, S355 and ASTM A572 Gr.50. Other grades can be confirmed according to project requirements.
Yes. Painted, epoxy coated, galvanized and other anti-corrosion treatments can be discussed according to marine, riverbank or long-term outdoor applications.
Please provide section type, steel grade, thickness, width, length, quantity, surface treatment, destination port and trade terms.
Yes. MTC, quality documents, inspection photos, packing photos, loading photos and third-party inspection can be provided according to order requirements.
Looking for steel sheet piles for retaining walls, cofferdams, ports or foundation construction?
Send us your required section type, grade, length, quantity and destination port. Henan GDD will provide a professional quotation and suitable shipping solution.
